Table size 1400 x 1600 mm. Table Tee Slot Dimensions (size x number x pitch) 27 x 7 x 200 mm. Max table load 7000Kg. Travels X/Y/Z/W 2000/1600/1500/500mm. Spindle Taper No. 50 ISO. Max Spindle Speeds 3000rpm. Spindle Drive 4 Shift Gear. Spindle Dia. 100 mm. Spindle Sleeve 225 mm. Feedrate 1 - 5000 mm/min. Tool magazine Carousel Tool capacity 40. Max standard tool diameter 125 mm. Max oversize tool diameter 250 mm. Max tool length 400 mm. Max tool weight 25Kg. Spindle Motor 18.5kW. Power requirement 60KVA. Electrical Supply 415V 3Phase. 50Hz. Air Pressure 6.5Kg/CM2. 3000rpm. Geared Head 26kW. Fully Enclosed Guarding for CTS. Through spindle coolant 20 Bar. 3 Axis Linear Scales. Oil Cooler. Link Type Swarf Conveyor and Tipping Skip. Hartford 310mm Long Spindle Support.

Machine Cutting Time 2095 Hours. Machine has had very little use and is in exceptional condition.

In addition to the machine we are offering on behalf of the client the following related accessories

COGSDILL 2.1/16" & 5.1/8" Seat Pocket/Outfacing Bars

ITS CH16 Contouring Head

These additional items are for sale by Negotiation directly with the auctioneers and priority will be given to the purchaser of the main HARTFORD PBM115AG CNC Horizontal Borer

All agreed prices will be subject to a 15% Buyers Premium

Spindle 10HP Variable Spindle Speed with Yaskawa Inverter Drive. Spindle Speeds 25 - 2,500rpm. Spindle Bore 80mm. Spindle Nose D1-8 Camlock. Speed Ranges 3 Ranges High 140 - 2,500rpm / Med 50 - 850rpm / Low 25 - 300rpm. Spindle Taper MT7 in bush. Swing Over Bed 480mm. Swing in Gap 700mm. Gap in front of Faceplate 170mm. Gap in front of Faceplate. Cross Slide Travel 230mm. Distance between Centres 1250mm. Maximum Cutting Length 1080mm. Tailstock Travel 160mm. Tailstock Taper MT5. Tailstock Diameter 75mm. Bed Width 370mm. Ballscrews X & Z. Servo Motors X & Z.

3 & 4 Jaw Chuck. Steady

Dimensions (L x D x H) 2600 x 1480 x 1830 mm. Machine Weight 2700Kg
