CNC Lathe
Los 1: FORCE ONE TC-3523 x 2300mm CNC Slant Bed Lathe with Fanuc Series 0i-TD Control. Year 2012
Swing over bed 660mm. Swing over cross slide 480mm. Maximum turning dia. 500mm. Maximum turning length 2315m. X/Z travel 250 +25mm/2250mm. Rapids X/Z 12/15m/min. Feed rates X/Z 0.001mm/500mm/min. Spindle nose A2-11. Spindle speeds (Geared) Low to 625 rpm (High) to 2500 rpm. Spindle Motor Power (continuous) 22kW. Spindle Motor Power (30 minutes) 26kW. Bar capacity 116mm. Fitted with 385mm dia. 3 jaw chuck. 12 station turret. 2 x Fixed steadies 210mm dia & 410mm dia. capacity. Tailstock dia/stroke 110mm/100mm. Tailstock Taper No.5MT. Turret tooling. Oil Cooler. Transformer. Swarf Conveyor. Fanuc Series 0i-TD Control. Machine Manuals. Machine dimensions L x W x H 5924mm (6824mm with swarf conveyor) x 2130mm x 2235mm high. Approximate weight 13,700 kg.
Los 2: HARDINGE GS200/66 CNC Lathe with Siemens Sinumerik 810D Control. Year 2007
Maximum machining dia. 284mm. Maximum swing over slideway covers 457mm. Travel X/Z 153mm/406mm. Rapids X/Z 30m/min. Spindle speeds 5000rpm. 12 station turret. Tailstock taper 4MT. Coolant capacity 125 litre. Machine complete with 3 jaw powered chuck. Collet Chuck. Assortment of Collets. Toolholders. Siemens Sinumerik 810D Control.Machine dimensions L x W x H 1998mm x 1650mm x 1881mm. Approximate weight 4950 kg
Los 3: XYZ 200TC CNC Lathe with Siemens 810D CNC Control. Barfeed and Swarf Conveyor
Maximum swing 420mm. Maximum turned dia. 200mm. Maximum turned length 550mm. Spindle bore 62mm. Bar capacity 52mm. Spindle speed 4800 rpm. 12 station turret (VDI). Spindle power 14.9kW. Fitted with Hydraulic 200mm dia. 3 jaw chuck. Tool Setting Arm. Swarf Conveyor. Remote Electronic Handwheel. Multifeed Barfeed. Hydraulic Tailstock. Siemens 810D CNC Control. Weight 4100kg
Los 8: DAEWOO Puma CT250 CNC Lathe with Fanuc 21i-T. Swarf Conveyor. Year 2002
Swing over bed 570mm. Turning dia. 420mm. Maximum turning length 650mm. Spindle speeds 3500 rpm. Machine complete 3 jaw powered chuck. 10 station turret. Tailstock. Swarf conveyor. Swarf Bin. Toolsetter. Fanuc 21i-T Control.
Los 9: DAEWOO Puma 8-2SP Twin Spindle / Twin Turret CNC Lathe with Fanuc Series 0-TT Control. Year 1996
2 x 205mm dia Chucks. 8 Tool Turrets. Spindle Speeds 3500rpm. Max. Turning Dia. 300mm. Max. Turning Length 200mm. Serial No: 2SP80170. Machine Dimensions L x W x H 4000mm x 3000mm x 2200mm. Approx Weight. 6500kgs.
Los 11: HURCO TM8 CNC Lathe with WinMax Control. Year 2005
Maximum swing 525mm dia. Maximum Cutting Diameter 356mm. Maximum Cutting Length 483mm.Bar capacity 51mm.10 station turret. Spindle speed 4,800 rpm. Spindle nose A2-6. Spindle power 16 kW. X travel 203mm. Z travel 508mm. Tailstock. Toolsetter. Swarf conveyor. Parts catcher. Rigid tapping. 3D Graphics. Machine complete with 3 jaw 200mm dia. powered chuck. Turret tooling. Bar puller. Coolant. Machine dimensions L x W x H. 2950mm x 2300mm x 2032mm. Approx weight 3700kgs.
Los 12: VICTOR TNS-1A CNC Lathe with Fanuc 10T-A Control. Year 1985
12 Tool Turret. Spindle Speeds upto 6000rpm. Machine dimensions L x W x H. 3150mm x 1450mm x 1900mm. Approx. weight 3000kgs. Serial No: NJ-0029
